LARGE DISPLAYS

OMD 202RS is available as either a 4- or 6-digit data display depending on model. LEDs can be either mono-color high brightness, or 3-color. The color can change according to the displayed value. Serial data output options are RS232/485 with selectable protocol and data formats. The display is designed for both indoor panel mounting as well as outdoor use and is sealed against ingress of water and dust to an IP 64 rating. Cables are connected through grommets. The OMD 202RS display can be controlled using an IR remote control. Wall mount kit is available.

Model OMD 202UNI is available as either a 4- or 6-digit programmable large display depending on model. Based on a fast 24-bit single-chip microcontroller with A/D convertor, it can be configured for any of eight input types which are easily selectable in the instrument's menu. It also ensures high accuracy, stability and ease of control. LEDs can be either mono-color high brightness, or 3-color. The LEDs color can change according to the displayed value. The display is designed for both indoor panel mounting as well as outdoor use and is sealed against ingress of water and dust to an IP 64 rating. Cables are connected through grommets. The OMD 202UNI display can be controlled using an IR remote control. Wall mount kit is available.

Model OMD 202UQC is available as either a 4- or 6-digit programmable large display depending on model. It measures count / frequency / duty cycle / IRC signals / time (clock/timer, stopwatch). Based on a single-chip microcontroller with a gate array, it is designed for high accuracy, stability and ease of control. LEDs can be either mono-color high brightness, or 3-color. The color can change according to the displayed value. The display is designed for both indoor panel mounting as well as outdoor use and is sealed against ingress of water and dust to an IP 64 rating. Cables are connected through grommets. The OMD 202UQC display can be controlled using an IR remote control. Wall mount kit is available.
